Pressure transmitters
Pondus Instruments offers a range of high-quality pressure transmitters designed for various industrial applications. The PT-series consists of several models, all equipped with advanced digital electronics to ensure maximum precision and flexibility. These pressure transmitters cater to a wide range of needs, with variations in design, price, and performance, making them suitable for industries such as oil and gas, water treatment, and manufacturing. Each model comes with specific features and options, such as piezo resistive sensors, direct process connections, and scalable pressure ranges.
PT01 digital transmitter for Gauge or Absolute pressure and Level.
PT01 the compact transmitter for different application well suited when there are need for high volume, special design and competitive price.
- Pressure range 35 kPa to 20 bar
- Absolute or gauge pressure
- Accuracy 0,5…1%
- Different outputs 0-5 vdc, 0-10 vdc, 4-20 mA
- Power supply 8 to 36 vdc.
- Datasheet
PT03 digital transmitter for Gauge or Absolute pressure and Level.
The PT03 model is a digital pressure transmitter designed for gauge or absolute pressure and level measurements. It features a piezo resistive pressure sensor connected to the pressure media via a 316L diaphragm. The PT03 is available with various threaded connections and can be calibrated and configured through an external display or the PI200 PC software. This model offers:
- Different threaded connections.
- Pressure range 0,35 bar to 35 bar
- Innovative Autozero function
- High accuracy 0,25% (option 0,15%).
- Output 4-20 mA and Modbus RTU over RS485
- Flexible scalable range Turn Down 10:1
- Power supply 8 to 36 vdc
PT06 digital transmitter for Gauge or Absolute pressure and Level.
The PT06 is a versatile pressure transmitter for gauge or absolute pressure and level measurement. This model has a piezo resistive pressure sensor connected to the media via a capillary tube, offering 23 different process connections. PT06 is modular, making it adaptable to a wide variety of applications. Key features include:
- Directly connected process connections without pressure intermedia
- Pressure range 35 kPa to 150 bar
- Scalable range TD 10:1
- High accuracy 0,2% and very low temperature drift.
- Output 4-20 mA and Modbus RTU over RS485
- Power supply 8 to 36 vdc.
- Display option for transmitter settings and display of Process Value.
PT600 advanced digital transmitter for Gauge-, Absolute-, Differential- Pressure and Level.
The PT600 is a high-performance digital pressure transmitter suitable for gauge, absolute, and differential pressure, as well as level measurement. It is built to handle a wide range of process connections, making it ideal for various industrial environments. Features include:
- Directly connected process connections without pressure intermedia
- Pressure range 35 kPa to 150 bar
- High accuracy 0,075% and very low temperature drift.
- Turn Down 100:1
- Output 4-20 mA/Hart and Modbus RTU over RS485
- Power supply 8 to 55 vdc.
- Display option for transmitter settings and display of Process Value.
PT60 advanced digital transmitter for Gauge-, Absolute- Pressure and Level.
The PT60 is an advanced transmitter for gauge and absolute pressure measurement, with level monitoring capabilities. Designed for challenging industrial environments, the PT60 features modular construction, offering 23 different process connections and an Exia-approved electrical port for hazardous areas. Notable features include:
- Directly connected process connections without pressure intermedia
- Pressure range 35 kPa to 20 MPa
- High accuracy 0,1 % (option 0,05%) and very low temperature drift
- Turn Down 30:1
- Output 4-20 mA/Hart
- Power supply 9 to 55 vdc
- Display option
Product | PT01 | PT03 | PT06 | PT600 | PT60 |
Pressure range | 35 kPa to 35 bar | 35 kPa to 35 bar | 35 kPa to 35 bar | 60 mbar…400* bar | 35 kPa to 150 bar |
Accuracy | ±0,50% | ±0,35% | ±0,2% | ±0,075% | ±0,1% |
Turn Down | 1:1 | 10:1 | 10:1 | 100:1 | 30:1 |
Output | 0-5 volt 0-10 volt | 4-20 mA | 4-20 mA | 4-20 mA | 4-20 mA |
Communication |
| Modbus RTU | Modbus RTU | Modbus RTU Hart | Hart |
PI200PS configuration tool | Fixed | √
| √
| √ | PI100 |
Integrated display on transmitter | √ | √
| √ | ||
directly connected process connection |
|
| √ | √ | √ |
Intrinsically safe | √* | √ | |||
Two Sensor | √ | ||||
Differential Pressure | √ | ||||
Options | Special request | 0,15% accuracy | Display, 0,15% accuracy Electrical port | Display, 0,05% accuracy, Electrical port | Display, 0,05% accuracy, Electrical port |
Pressure Transmitter: An Essential Tool for Accurate Pressure Measurement
Pressure transmitters play a critical role in monitoring and controlling pressure in various industrial processes. At Pondus Instruments, we specialize in manufacturing high-quality pressure transmitters designed to meet the needs of diverse industries, from water treatment to tunneling.
What is a Pressure Transmitter?
A pressure transmitter is a device that converts pressure into an analog electrical signal. These transmitters are used to measure various forms of pressure, including relative, absolute, and differential pressure. They are essential in ensuring safety, efficiency, and accuracy in industrial operations.
Types of Pressure Transmitters
Pondus Instruments offers a wide range of pressure transmitters to suit different applications:
- General-purpose pressure transmitters:Perfect for measuring pressure in industrial and process systems.
- Differential pressure transmitters: Used to measure the difference in pressure between two points, crucial for process control in sectors like water treatment and paper production.
- Submersible pressure transmitters: Designed for level measurement in tanks, wells, and reservoirs.
- Specialized TBM pressure transmitters: Developed for measuring ground pressure in tunneling operations.
Each product is manufactured with precision to ensure reliability and durability, even in challenging environments.
Key Features of Pondus Instruments’ Pressure Transmitters
Our pressure transmitters are known for their advanced features, including:
- High accuracy: Ensures precise pressure measurement for critical processes.
- Customizable configurations: Options for various process connections and pressure ranges.
- Durable construction: Resistant to harsh environments, including extreme temperatures and corrosive materials.
- Ease of integration: Compatible with existing industrial systems.
These features make our transmitters suitable for a wide range of applications, from monitoring fluid levels in food production to controlling pressures in wastewater treatment plants.
Applications of Pressure Transmitters
Pondus Instruments’ pressure transmitters are trusted by industries worldwide for applications such as:
- Water and wastewater management: Ensuring optimal pressure in treatment systems.
- Food and beverage production: Maintaining consistent pressure in pipelines and tanks.
- Tunneling and construction: Monitoring ground pressure during excavation.
- Pulp and paper industry: Managing pressure in production equipment.
By offering tailored solutions, we help industries enhance process control and operational efficiency.
Why Choose Pondus Instruments for Your Pressure Transmitter Needs?
With decades of experience in the field, Pondus Instruments provides innovative solutions tailored to industry requirements. Founded in 1993, the company is dedicated to delivering high-performance products that meet international standards. Our expertise spans multiple sectors, allowing us to cater to specific needs with precision-engineered pressure transmitters.
Contact Us
If you’re looking for reliable and accurate pressure transmitters, Pondus Instruments is your trusted partner. Explore our range of pressure transmitters above or contact our team for expert guidance on selecting the right transmitter for your needs.
